GoodWe 5kW Hybrid Inverter | 48V Dual MPPT

A versatile, all-in-one solution for smart energy management. The GoodWe ES series intelligently manages power from solar panels, batteries, and the grid to ensure your home stays powered 24/7.

• Hybrid Power: Supports On-Grid, Off-Grid, and UPS modes.

• High Charging Capacity: Integrated 100A battery charger for fast storage.

• Smart Monitoring: Built-in Wi-Fi for remote performance tracking via the GoodWe app.

• Safe & Reliable: IP65 weatherproof rating with a fanless, low-noise design.

   Technical Specifications

  • Type: 5kW Single-Phase Bi-directional Hybrid.

  • Solar Input: Max 6500W PV with Dual MPPT trackers ($125\text{V}-550\text{V}$).

  • Battery: 48V Nominal; 100A Max Charge/Discharge current.

  • Backup: $<10\text{ms}$ UPS-level switching for uninterruptible power.

  • Surge Power: 6900VA peak (10 seconds) for heavy motor starts.

  • Efficiency: 97.6% Max / 99.9% MPPT efficiency.

  • Cooling: Fanless natural convection (completely silent operation).

  • Protection: IP65 Rated (Weatherproof for indoor/outdoor install).

  • Smart Features: Built-in Wi-Fi; supports Zero-Export with EzMeter.

  • Weight/Size: 30kg; $516\times 440\times 184\text{ mm}$.
